KEYGREE Welding Machine Model MZ-630/MZ-1000/MZ-1250/MZ-1600
MZ series arc welding power supply adopts IGBT soft switching inverter technology. The input is three-phase 380VAC 50Hz grid AC. After power frequency rectification and filtering, the inverter composed of IGBT is converted into 20KHz intermediate frequency AC, and then the intermediate frequency transformer is stepped down and rectified and filtered to obtain DC output that can meet the welding needs. The output parameters are fed back to the control system and integrated with the given parameters to meet the welding output characteristics and achieve stable welding output parameters. The control system simultaneously provides the welding parameters to the digital display to display the welding parameters in real time. Through the role of the relevant system, the dynamic response speed of the welder is increased, and the size and weight of the welder are reduced. Adopting closed-loop control mode, MZ series arc welding power source has good resistance to grid fluctuation and excellent welding performance. The scope of application is quite extensive.
Included:
- With Tractor
- Control box
- Boat-shaped welding trolley
- 15m control cable (12 core 1mm²), 1pc
- 15m connect cable (95mm²)，1pc
- 5m earth cable(95mm²)+500Aclamp,2pcs
- Contact tip Ø3.2, 1pc
- Contact tip Ø4.0, 1pc
- Contact tip Ø5.0, 1pc
- Wire feeder Ø3.0-Ø4.0, 2pcs
- Wire feeder Ø4.2-Ø5.0, 2pcs
- Manual
3-IN-1 VERSATILITY
Due to its versatility, this machine enables you to perform the following tasks: manual arc welding (MMA) using a direct current mainly coated electrode, submerged arc welding, and hole drilling.
DIGITAL DISPLAY
Above the control panel, there are two digital screens which are used to accurately display the welding current and voltage, allowing for easy adjustment of the welding mode. The digital welding current display shows the set current value in the setting mode. During the welding process, it displays the actual welding current value.
EXTENDED EQUIPMENT
A welding tractor is equipped with control cables, welding and return cables, a set of wire feed tips and rollers, ship welding blocks and other related and consumable materials, allowing you to get started quickly.
