TEKMA TLF-STP Enclosed Sheet and Tube Laser Cutting Machine
SKU : 10101400
More safe and environmentally friendly
Description
Product Description
- This equipment is capable of simultaneously processing both sheet metal and pipe components, making it widely used in the sheet metal fabrication and parts manufacturing industries
- The front cutting area is enclosed with a protective casing and equipped with a high-performance dust removal system, ensuring high safety, environmental friendliness, and protection against radiation
- Equipped with two monitoring cameras, displaying the cutting head view and the progress of material loading and unloading on the rear bed. It can be connected to the factory's internal monitoring system, enhancing safety
Technical Parameters
| Mode | TLF-3015STP | TLF-6015STP | TLF-4020STP | TLF-6025STP |
| Working Area | 3000*1500mm | 6000*1500mm | 4000*2000mm | 6000*2500mm |
| X Y Z Axis Stroke | 1520*3100*100mm | 1520*6050*100mm | 2040*4050*100mm | 2510*6100*260mm |
| Laser Power Supply | 2000W, 3000W, 6000W | |||
| Maximum Acceleration | φ20mm~φ230mm, 20mm~230mm | |||
| Positioning Accuracy | ±0.03mm | |||
| Voltage | 380V 50HZ | |||
| Cutting Ability | Carbon Steel: 1-80mm, Stainless Steel: 1-70mm, Aluminum: 1-60mm, Brass: 1-20mm, Tube Cutting ThicKness Will be the half of sheet | |||
| Upgrade | Air Conditioner, Smoke Purifier, Air Compressor, Voltage Regulator, Safety Light Curtain | |||
